Safety IV Cannula Without Injection Port and Wing

USP Class VI certified (catheter material) EN ISO 10555 certified (color-coding standard) EN ISO 10993-7 certified (sterilization residual limits)

Questions about this product? — our team will reach out.

Uncategorized

Safety IV Cannula Without Injection Port and Wing

$24

Pen-like, wingless design: : This safety cannula is a peripheral IV cannula engineered for maneuverability and strong infection control.

Automatic needle shield: : Fully encapsulates the needle tip immediately upon withdrawal.

Biocompatible catheter material: : Made from kink-resistant PUR that softens at body temperature.

Latex-free: : Free from elasticized PVC and approved for Taxol administration.

Top Highlights

Profile: Straight, wingless, no injection port
Catheter Material: PUR (polyurethane)
Safety Feature: Automatic needle shield
Latex-Free: Yes

Buy Now

Guaranteed Safe And Secure Checkout

This safety cannula is a streamlined, pen-like peripheral intravenous cannula built for precise clinical access and strong infection control. Its straight, wingless profile suits specialized insertion techniques, while an automatic safety shield encapsulates the needle tip the moment it's withdrawn, helping protect healthcare workers and waste handlers from needlestick injuries and bloodborne pathogen exposure. The catheter is made from biocompatible, kink-resistant PUR material designed to reduce mechanical stress on the blood vessel, and the device is free from latex and elasticized PVC.

6 Gauge sizes available (14G to 24G)

96 hrs Maximum recommended dwell time

5 yrs Shelf life from manufacture

EtO Sterilization method

Key features

1 Automatic needle safety shield:

Fully encapsulates the needle tip upon withdrawal, reducing the risk of needlestick injury.

2 Tapered hub and catheter tip:

Aligns smoothly with the needle bevel for easier insertion and reduced patient discomfort during peripheral intravenous cannula placement.

3 Large flashback chamber:

Gives a clear visual confirmation of venipuncture, helping avoid repeated puncture attempts.

4 Kink-resistant PUR catheter:

Softens at body temperature and is built to lower the risk of mechanical phlebitis during extended use in this peripheral cannula.

5 Radiopaque catheter lines:

Allow the catheter to be clearly visualized under X-ray.

6 Ergonomic thumb grip:

Designed to accommodate a range of insertion techniques and angles.

7 Latex-free construction:

Free from natural rubber latex and elasticized PVC, making it a suitable IV cannula for adult patients undergoing Taxol administration.

14G	Orange, 2.1 mm, 270 ml/min, 30/45 mm
16G	Grey, 1.8 mm, 200 ml/min, 30/45 mm
18G	Green, 1.3 mm, 85 ml/min, 32/45 mm
20G	Pink, 1.1 mm, 55 ml/min, 25/32 mm
22G	Blue, 0.9 mm, 33 ml/min, 19/25 mm
24G	Yellow, 0.7 mm, 18 ml/min, 19 mm
Needle Material	Siliconized stainless steel
Catheter Material	Biocompatible PUR, USP Class VI
Sterilization	Terminal ethylene oxide (EtO); residuals within EN ISO 10993-7 limits
Latex-Free	Yes

USP Class VI certified (catheter material)

EN ISO 10555 certified (color-coding standard)

EN ISO 10993-7 certified (sterilization residual limits)

Batch-tested for leakage, lumen flow rate, and penetration force

Select the right size:: Choose the appropriate gauge and length for this peripheral IV cannula based on clinical requirements.

Use aseptic technique:: Insertion must be performed by a qualified healthcare professional.

Confirm access:: Check venous access through the flashback chamber.

Activate the shield:: Withdraw the needle to activate the automatic safety shield.

Connect and secure:: Attach compatible IV equipment and secure the cannula in place.

Dispose safely:: Discard the used device in an appropriate sharps container.

Professional use only:

This safety cannula is intended for use only by a qualified doctor or paramedic.

Irreversible safety shield:

Activates automatically upon needle withdrawal to prevent reuse and reduce needlestick risk.

Maximum dwell time:

ecommended maximum time of use is 96 hours, per CDC guidelines.

Sharps disposal:

Blood-contaminated sharps must be discarded in puncture-resistant containers and incinerated per standard hospital protocol.

Storage:

Store in a cool, dry environment away from direct sunlight and moisture.

Latex-free:

Free from natural rubber latex and elasticized PVC.

What gauge sizes are available for this cannula?

14G, 16G, 18G, 20G, 22G, and 24G, each color-coded per EN ISO 10555.

What safety feature does this cannula include?

As a safety cannula, it includes an automatic needle shield that fully encapsulates the needle tip immediately upon withdrawal, reducing the risk of needlestick injury.

What material is the catheter made from?

A biocompatible, kink-resistant PUR (polyurethane) material that meets USP Class VI standards.

Is this cannula latex-free?

Yes, it contains no natural rubber latex or elasticized PVC, and is approved for Taxol administration.

How long can this cannula remain in place?

The recommended maximum time of use is 96 hours, per CDC guidelines.

How is this device sterilized?

Using terminal ethylene oxide (EtO) gas sterilization, with residuals maintained within EN ISO 10993-7 limits.

Who can use this device?

It is intended for use only by a qualified doctor or paramedic for peripheral venous access.
